Geist Switched Unit Level Monitoring MNS5MGB1-24CF18-3TL6A0A10-S

$2,464.00

Mfr Part #:

Copied To Clipboard

Click To Copy

SHI Part #:

Copied To Clipboard

Click To Copy

Quick Details
Power distribution unit (rack-mountable) AC 208 V 4.9 kW RS-232, USB, Ethernet 10/100/1000 input: NEMA L6-30P

Geist Switched Unit Level Monitoring MNS5MGB1-24CF18-3TL6A0A10-S

Power distribution unit (rack-mountable)
AC 208 V
4.9 kW
RS-232, USB, Ethernet 10/100/1000
input: NEMA L6-30P
output connectors: 24 (IEC 60320 C13/C19)
0U
3 m cord
black powder coat
TAA Compliant

Additional Details
Price:	$2,464.00
Mfr Part #:	VP5N30AP
SHI Part #:	48210981
Category:	Rack systems for rack mount electroni...
UNSPSC:	24102001
Manufacturer:	Vertiv
Product Type:	Hardware

General Information
Category	Rack systems for rack mount electroni...
Description	Geist Switched Unit Level Monitoring MNS5MGB1-24CF18-3TL6A0A10-S - Power distribution unit (rack-mountable) - AC 208 V - 4.9 kW - RS-232, USB, Ethernet 10/100/1000 - input: NEMA L6-30P - output connectors: 24 (IEC 60320 C13/C19) - 0U - 3 m cord - black powder coat - TAA Compliant
Manufacturer	Vertiv
MSRP	$3,433.00
UNSPSC	24102001
Main Specifications
Dimensions & Weight / Depth	6.6 cm
Dimensions & Weight / Height	168.3 cm
Dimensions & Weight / Width	5.1 cm
General / Subcategory	Power distribution devices
Header / Brand	Geist
Miscellaneous / Product Color	Black
Networking / Remote Management Interface	Ethernet 10/100/1000 RS-232 USB
Packaged Quantity	1
Power Device / Form Factor	Rack-mountable
Power Device / Output Connector Qty	24
Power Device / Voltage Required	AC 208 V
Product Type	Power distribution unit
Service & Support / Type	5-year warranty
Dimensions & Weight
Depth	6.6 cm
Height	168.3 cm
Width	5.1 cm
Dimensions & Weight (Shipping)
Shipping Weight	9.07 kg
Environmental Parameters
Max Operating Temperature	60 °C
Expansion / Connectivity
Interfaces	2 x management (Fast Ethernet) - RJ-45 1 x sensor 1 x RS-232 - RJ-45 1 x USB
General
Color	Black powder coat
Cord Length	3 m
Device Type	Power distribution unit - rack-mountable
Height (Rack Units)	0U
Manufacturer Warranty
Service & Support	Limited hardware warranty - 5 years with product registration (within 120 days of purchase) Limited warranty - 3 years
Miscellaneous
Cables Included	Power cable 3 m
Compliant Standards	UL, RoHS, FCC Part 15 A, UL 62368-1, C-UL
Features	Vertical orientation, LED display, circuit/breaker current monitoring, IP reset button, 2 x 20A double pole magnetic breakers, breaker/switch combination, hard reboot button, scrolling/rotatable digital display
TAA Compliant	Yes
Networking
Remote Management Interface	RS-232, USB, Ethernet 10/100/1000
Remote Management Protocol	SNMP 1, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, SMTP, NTP, DHCP, IPv4, IPv6, JSON, RSTP, TACACS+, LDAP, RADIUS, Syslog, Modbus TCP
Power Device
Circuit Protection	Circuit breaker
Frequency Required	50/60 Hz
Input Connectors	1 x power NEMA L6-30P
Input Voltage	AC 208 V
Max Electric Current	30 A
Power Capacity	4.9 kW
Power Output Connectors Details	24 x power IEC 60320 C13/C19
