NETGEAR Plus GS110EMX
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
NETGEAR Plus GS110EMX
- Switch
- managed
- 8 x 1000Base-T + 2 x 100/1000/2.5G/5G/10G (uplink)
- desktop, rack-mountable, wall-mountable
- DC power
| Additional Details | |
|---|---|
| Price: | |
| Mfr Part #: | GS110EMX-100NAS |
| SHI Part #: | 34417410 |
| Category: | Network switches |
| UNSPSC: | 43222612 |
| Manufacturer: | NETGEAR |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Network switches |
| Description | NETGEAR Plus GS110EMX - Switch - managed - 8 x 1000Base-T + 2 x 100/1000/2.5G/5G/10G (uplink) - desktop, rack-mountable, wall-mountable - DC power |
| Manufacturer | NETGEAR |
| MSRP | $300.09 |
| UNSPSC | 43222612 |
| Main Specifications | |
| Dimensions & Weight / Depth | 10.2 cm |
| Dimensions & Weight / Height | 2.7 cm |
| Dimensions & Weight / Weight | 750 g |
| Dimensions & Weight / Width | 23.6 cm |
| Header / Brand | NETGEAR |
| Header / Country Kits |
|
| Miscellaneous / Product Color | Gray |
| Networking / Form Factor |
|
| Networking / Ports Qty | 10 |
| Networking / Type | Switch |
| Packaged Quantity | 1 |
| Service & Support / Type | Limited lifetime warranty |
| Dimensions & Weight | |
| Depth | 10.2 cm |
| Height | 2.7 cm |
| Weight | 750 g |
| Width | 23.6 cm |
| Environmental Parameters | |
| Humidity Range Operating | 90% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Max Storage Temperature | 70 °C |
| Min Operating Temperature | 0 °C |
| Min Storage Temperature | -20 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| General | |
| Capacity |
|
| Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3az |
| Device Type | Switch - 10 ports - managed |
| Enclosure Type | Desktop, rack-mountable, wall-mountable |
| Features | Flow control, full duplex capability, IGMP snooping, port mirroring, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, DDos attack prevention, fanless, 128KB packet buffer, LACP support, Link Aggregation Control Protocol (LACP), DHCP client, security lock slot (cable lock sold separately), DiffServ Code Point (DSCP) support, cable test, Link Aggregation, Voice VLAN, Energy-Efficient Ethernet (EEE), Weighted Round Robin (WRR), VLAN Tagging, port-based VLAN |
| Jumbo Frame Support | 10240 bytes |
| MAC Address Table Size | 16K entries |
| Performance | Bandwidth: 56 Gbps |
| Ports | 8 x 1000Base-T + 2 x 100/1000/2.5G/5G/10G (uplink) |
| Status Indicators | Power, link/activity |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - advance parts replacement - lifetime - response time: next business day |
| Miscellaneous | |
| Compliant Standards | CB, UL 60950-1, KC, EAC, CNS 13438, EN 61000-3-3:2013, EN 61000-3-2:2014, FCC CFR47 Part 15 B Class B, EN 55024:2010+A1:2015, EN 55032:2012+AC:2013 Class A, AS/NZS CISPR 32 Class B, ANSI C63.4-2014, AS/NZS 60950-1:2015, CISPR 32:2012, CAN/CSA-C22.2 No. 60960-1-07, IEC60950-1:2005, Second edition + A1:2009 + A2:2013, ICES-003:2016 issue 6 Class B, AS/NZS CISPR 32:2013 Class B, EN 55032:2015+AC:2016, CISPR 32:2015+COR1:2016, VCCI-CISPR 32:2016 Class B, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 |
| Included Accessories | Rubber feet, rack mount kit, wall mounting kit |
| Localization | Latin America, North America |
| Rack Mounting Kit | Included |
| Power | |
| Electric Current Required | 1.5 A |
| Power Consumption Operational | 15.6 Watt |
| Power Device | External power adapter |
| Voltage Required | DC 12 V |
