NETGEAR GS324P - Switch
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
NETGEAR GS324P - Switch
- unmanaged
- 16 x 10/100/1000 (PoE+) + 8 x 10/100/1000
- desktop, rack-mountable
- PoE+ (190 W)
| Additional Details | |
|---|---|
| Price: | |
| Mfr Part #: | GS324P-100NAS |
| SHI Part #: | 38676742 |
| Category: | Network switches |
| UNSPSC: | 43222612 |
| Manufacturer: | NETGEAR |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Network switches |
| Description | NETGEAR GS324P - Switch - unmanaged - 16 x 10/100/1000 (PoE+) + 8 x 10/100/1000 - desktop, rack-mountable - PoE+ (190 W) |
| Manufacturer | NETGEAR |
| UNSPSC | 43222612 |
| Main Specifications | |
| Dimensions & Weight / Depth | 20.6 cm |
| Dimensions & Weight / Height | 4.3 cm |
| Dimensions & Weight / Weight | 2.44 kg |
| Dimensions & Weight / Width | 33 cm |
| Header / Brand | NETGEAR |
| Header / Country Kits |
|
| Miscellaneous / Product Color | Black |
| Networking / Form Factor |
|
| Networking / Ports Qty | 24 |
| Networking / Type | Switch |
| Packaged Quantity | 1 |
| Service & Support / Type | 3-year warranty |
| Dimensions & Weight | |
| Depth | 20.6 cm |
| Height | 4.3 cm |
| Weight | 2.44 kg |
| Width | 33 cm |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Humidity Range Storage | 10 - 95% (non-condensing) |
| Max Operating Temperature | 45 °C |
| Max Storage Temperature | 70 °C |
| Min Operating Temperature | 0 °C |
| Min Storage Temperature | -20 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| General | |
| Compliant Standards | IEEE 802.3at, IEEE 802.1p, IEEE 802.3az, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3i, IEEE 802.3 |
| Device Type | Switch - 24 ports - unmanaged |
| Enclosure Type | Rack-mountable, desktop |
| Features | Auto-uplink (auto MDI/MDI-X), auto-negotiation, WRR, full duplex mode, half duplex mode, CoS, DiffServ support, Energy Efficient Ethernet, 1 fan |
| Jumbo Frame Support | 10000 bytes |
| MAC Address Table Size | 8K entries |
| Performance |
|
| PoE Budget | 190 W |
| Ports | 16 x 10/100/1000 (PoE+) + 8 x 10/100/1000 |
| Power Over Ethernet (PoE) | PoE+ |
| Status Indicators | Link/activity/speed, PoE, power, fan |
| Subtype | Gigabit Ethernet |
| Manufacturer Warranty | |
| Service & Support |
|
| Miscellaneous | |
| Compliant Standards | FCC Part 15 A, IC Class A, RCM, VCCI, KC, CB, LVD, UL |
| Included Accessories | Rubber feet |
| Localization | North America, Asia Pacific |
| MTBF | 1,193,574 hours |
| Rack Mounting Kit | Included |
| Power | |
| Installed Qty | 1 |
| Power Consumption Operational | 210 Watt |
| Power Consumption Stand by | 10 Watt |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
