NVIDIA RTX - Graphics card
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
NVIDIA RTX - Graphics card
- RTX A5500
- 24 GB GDDR6
- PCIe 4.0 x16
- 4 x DisplayPort
| Additional Details | |
|---|---|
| Mfr Part #: | 900-5G132-2270-000 |
| SHI Part #: | 45413813 |
| Category: | Graphic accelerator cards |
| UNSPSC: | 43201401 |
| Manufacturer: | NVIDIA |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Graphic accelerator cards |
| Description | NVIDIA RTX - Graphics card - RTX A5500 - 24 GB GDDR6 - PCIe 4.0 x16 - 4 x DisplayPort |
| Manufacturer | NVIDIA |
| UNSPSC | 43201401 |
| Main Specifications | |
| A/V Interface Type | PCI Express 4.0 x16 |
| Dimensions & Weight / Depth | 26.7 cm |
| Dimensions & Weight / Height | 11.2 cm |
| Header / Brand | NVIDIA |
| Packaged Quantity | 1 |
| Video Memory / Technology | GDDR6 SDRAM |
| Video Output / Graphics Processor | NVIDIA RTX A5500 |
| Video Output / Graphics Processor Manufacturer | NVIDIA |
| General | |
| API Supported | Direct3D 12, Shader Model 6.6, OpenGL 4.6, Vulkan 1.3, CUDA 11.6, DirectCompute, OpenCL 3.0 |
| Bus Type | PCI Express 4.0 x16 |
| CUDA Cores | 10240 |
| Device Type | Graphics card |
| Features | Error Correcting Codes (ECC) Memory, NVIDIA Ampere GPU technology, 320 NVIDIA Tensor Cores, 80 NVIDIA RT Cores, 34.1 Tflops peak single-precision floating point performance, 66.6 Tflops RT Core performance, 272.8 Tflops tensor performance, dual slot width, 3rd gen Tensor Cores, 2nd gen Ray Tracing Cores, NVIDIA NVLink technology, NVIDIA Mosaic, Quadro Sync 2, Nvidia GPUDirect, 3D Stereo Connectivity, Nvidia Virtual GPU, NVIDIA RTX Experience, NVIDIA RTX 10 support, AV1 decode support, HDCP |
| Graphics Engine | NVIDIA RTX A5500 |
| Interfaces Details | 4 x DisplayPort |
| Max Monitors Supported | 4 |
| Max Resolution | 7680 x 4320 at 60 Hz |
| Max Resolution Details | DisplayPort: 7680 x 4320 at 60 Hz (dual displays) / 5120 x 2880 at 60 Hz (four displays) / 4096 x 2160 at 120 Hz (four displays) |
| VR Ready | Yes |
| Memory | |
| Bandwidth | 768 GBps |
| Bus Width | 384-bit |
| Size | 24 GB |
| Technology | GDDR6 SDRAM |
| Miscellaneous | |
| Compliant Standards | DisplayPort 1.4a, HDCP 2.2 |
| Depth | 26.7 cm |
| Height | 11.2 cm |
| Power Consumption Operational | 230 watt |
| System Requirements | |
| Additional Requirements | 8 pin PCI Express power connector |
