Hikvision DeepinView iDS-2CD7546G0-IZHSY
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Hikvision DeepinView iDS-2CD7546G0-IZHSY
- Network surveillance camera
- dome
- outdoor
- corrosion-proof / dustproof / waterproof / vandal-proof
- color (Day&Night)
- 4 MP
- 2560 x 1440
- motorized
- audio
- GbE
- MJPEG, H.264, H.265, H.265+, H.264+
- DC 12 V / AC 24 V / PoE Plus Class 4
| Additional Details | |
|---|---|
| Mfr Part #: | iDS-2CD7546G0-IZHSY(2.8-12mm) |
| SHI Part #: | 43800099 |
| Category: | Digital cameras |
| UNSPSC: | 45121504 |
| Manufacturer: | Hikvision |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Digital cameras |
| Description | Hikvision DeepinView iDS-2CD7546G0-IZHSY - Network surveillance camera - dome - outdoor - corrosion-proof / dustproof / waterproof / vandal-proof - color (Day&Night) - 4 MP - 2560 x 1440 - motorized - audio - GbE - MJPEG, H.264, H.265, H.265+, H.264+ - DC 12 V / AC 24 V / PoE Plus Class 4 |
| Manufacturer | Hikvision |
| UNSPSC | 45121504 |
| Main Specifications | |
| Dimensions & Weight / Depth | 16.2 cm |
| Dimensions & Weight / Height | 14.18 cm |
| Dimensions & Weight / Weight | 1.565 kg |
| Dimensions & Weight / Width | 16.2 cm |
| Header / Brand | Hikvision |
| Miscellaneous / Product Color |
|
| Packaged Quantity | 1 |
| Service & Support / Type | 3-year warranty |
| Camera | |
| Digital Video Capture Resolution | 1280 x 720, 640 x 480, 704 x 576, 704 x 480, 1920 x 1080, 2560 x 1440 |
| Digital Video Format | MJPEG, H.264, H.265, H.265+, H.264+ |
| Exposure Range | 1 sec - 1/100000 sec |
| Features | Backlight Compensation (BLC), sharpness control, digital image rotation, white balance, progressive scanning, saturation control, brightness control, contrast control, e-mail alerts, image mirror, Wide Dynamic Range (WDR), heater, face detection, Face Recognition, infrared cut filter, Privacy Mask Function, Highlight Compensation (HLC), Scene Change Detection, NAS-Ready, Electronic Image Stabilizer (EIS), tamper-detection, notification picture to E-mail, Smart IR, notification picture to FTP, reset button, password protection, distortion correction function, Region of Interest (ROI), Variable Bitrate (VBR), Constant Bitrate (CBR), Defog, intrusion detection, 3D Digital Noise Reduction Technology, Defocus Detection, ONVIF (Profile S) support, ONVIF (Profile G) support, object removal detection, image overlay, digest authentication, Line Crossing Detection, Object Counting, watermark, heartbeat, anti-flicker, Internet Server Application Programming Interface (ISAPI), unattended baggage detection, IP address filtering, region exiting detection, region entrance detection, human detection, up to 20 channels simultaneous live view, 5 video streams, environment noise filtering, IR anti-reflection window, aluminum housing, ONVIF (Profile T) support, Automatic Network Replenishment (ANR), Scalable Video Coding (SVC), body detection, smart supplement light, manual 355° rotation, DarkFighter technology, Gain Control, blue glass module, vibration detection, face counting, Target Cropping |
| Frame Rate (max) | 30 frames per second |
| Infrared Distance | 30 m |
| Infrared LEDs | Yes |
| Max Digital Video Resolution | 2560 x 1440 |
| Minimum Illumination |
|
| Motion Detection | Yes |
| Type | Color - Day&Night - fixed - outdoor - corrosion-proof / dustproof / waterproof / vandal-proof |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 21.5 cm |
| Shipping Height | 18.9 cm |
| Shipping Weight | 2.295 kg |
| Shipping Width | 25.1 cm |
| Environmental Parameters | |
| Max Operating Temperature | 60 °C |
| Min Operating Temperature | -40 °C |
| Relative Humidity (operating) | 0 - 95% (non-condensing) |
| Expansion / Connectivity | |
| Ports |
|
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| General | |
| Audio Formats | PCM, G.726, MP3, G.711, G.722.1, MP2L2 |
| Audio Support | Yes: built-in two microphones |
| Connectivity Technology | Wired |
| Depth | 16.2 cm |
| Device Type | Network surveillance camera |
| Form Factor | Dome |
| Height | 14.18 cm |
| Weight | 1.565 kg |
| Width | 16.2 cm |
| Image Sensor | |
| Type | 4 MP PS CMOS 1/1.8" |
| Interfaces | |
| Alarm Inputs Qty | 1 |
| Alarm Outputs Qty | 1 |
| Control Interface | RS-485 |
| Network Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ICMP, SNMP, RTSP, RTP, HTTPS, UPnP, TLS, IPv6, Bonjour, RTCP, PPPoE, SMB, IGMP, SSL, QOS, CIFS, SRTP, EAP, SFTP, NFS, ISAPI, ISUP, SDK |
| Lens Construction | |
| Diagonal Field of View (degree) | 48 - 141.1 |
| Focal Length | 2.8 mm - 12 mm |
| Focus Adjustment | Automatic, manual, semi-auto |
| Horizontal Field of View (degree) | 41.8 - 114.5 |
| Lens Iris | F/1.2-2.5 (P-Iris) |
| Optical Zoom | 4.3 x |
| Type | Motorized zoom |
| Vertical Field of View (degree) | 23.6 - 59.3 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Compliant Standards | CB, EMC, IC, NEMA Type 4X, UL 60950-1, FCC CFR47 Part 15 B, REACH, IP67, IK10, KC, RCM, RoHS 2011/65/EU, BIS, EN 61000-3-3:2013, Regulation EC 1907/2006, TLS v1.2, WEEE 2012/19/EU, EN 61000-3-2:2014, EN 55032:2015, LoA, IEEE 802.3at, IEC/EN 60950-1, IS13252-1 (2010)/A1:2013/A2:2015, IEEE 802.1x, AS/NZS CISPR 32:2015, EN 50130-4:2011+A1:2014, KN32:2015, KN35:2015, IEC 62262:2002, IEC60950-1:2005+Am1:2009+Am2:2013, EN 60950-1:2005+Am1:2009+Am 2:2013, ICES-003 issue 6:2016, NEMA 250-2018 |
| Panning | |
| Range (degree) | 0 to 355 |
| Power | |
| Power Requirements | DC 12 V / AC 24 V / PoE Plus Class 4 |
| Tilting | |
| Range (degree) | 0 to 75 |
