Fortinet FortiGate 80F-POE

$6,527.00
Fortinet FortiGate 80F-POE
Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • Security appliance
  • with 3 years 24x7 FortiCare Support + 3 years FortiGuard Unified Threat Protection (UTP)
  • 1GbE
  • desktop / wall / rack mountable
Fortinet FortiGate 80F-POE
  • Security appliance
  • with 3 years 24x7 FortiCare Support + 3 years FortiGuard Unified Threat Protection (UTP)
  • 1GbE
  • desktop / wall / rack mountable
  Additional Details
Price: $6,527.00
Mfr Part #: FG-80F-POE-BDL-950-36
SHI Part #: 43277763
Category: Firewall appliances
UNSPSC: 43222501
Manufacturer: Fortinet
Product Type: Hardware
General Information
CategoryFirewall appliances
DescriptionFortinet FortiGate 80F-POE - Security appliance - with 3 years 24x7 FortiCare Support + 3 years FortiGuard Unified Threat Protection (UTP) - 1GbE - desktop / wall / rack mountable
ManufacturerFortinet
MSRP$8,120.18
UNSPSC43222501
Main Specifications
Dimensions & Weight / Depth17.8 cm
Dimensions & Weight / Height6 cm
Dimensions & Weight / Weight1.4 kg
Dimensions & Weight / Width21.6 cm
Header / BrandFortinet
Miscellaneous / Product ColorWhite
Networking / Connectivity TechnologyWired
Networking / Data Link Protocol
  • Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
Networking / Form FactorDesktop / wall / rack mountable
Networking / TypeSecurity appliance
Packaged Quantity1
Environmental Parameters
Humidity Range Operating10 - 90% (non-condensing)
Max Operating Temperature40 °C
Min Operating Temperature0 °C
Expansion / Connectivity
Interfaces
  • 2 x 1000Base-T/1000Base-X - RJ-45/SFP (mini-GBIC)
  • 6 x 1000Base-T (PoE+) - RJ-45
  • 2 x 1000Base-T (FortiLink PoE+) - RJ-45
  • 1 x console - RJ-45
  • 1 x USB 3.0 - Type A
General
Bundled Services3 years 24x7 FortiCare Support + 3 years FortiGuard Unified Threat Protection (UTP)
Depth17.8 cm
Device TypeSecurity appliance
Height6 cm
Weight1.4 kg
Width21.6 cm
Miscellaneous
Compliant StandardsUL, VCCI, BSMI, ICSA IPSec certified, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FCC, ICES, RCM, ICSA SSL-VPN, ICSA IPS
Networking
Capacity
  • Concurrent TCP sessions: 1500000
  • New TCP sessions per second: 45000
  • Firewall policies: 5000
  • Gateway to gateway IPSec VPN Tunnels: 200
  • Client to gateway IPSec VPN tunnels: 2500
  • Concurrent SSL VPN users: 200
  • SSL inspection CPS: 700
  • SSL inspection concurrent sessions: 100000
  • Virtual domains: 10
  • Maximum virtual domains: 10
  • Number of FortiSwitches: 16
  • Number of FortiAP devices: 96
  • Number of FortiAP devices (tunnel): 48
  • Number of FortiToken devices: 500
Connectivity TechnologyWired
Data Link ProtocolEthernet, Fast Ethernet, Gigabit Ethernet
Encryption AlgorithmSSL, 256-bit AES, 256-bit SHA, TLS 1.3
FeaturesVPN support, 3G/4G USB Dongle Support, CAPWAP support, SSL inspection, SD-WAN support
Form FactorDesktop / wall / rack mountable
Network / Transport ProtocolTCP/IP, UDP/IP, IPSec, HTTP, HTTPs
Performance
  • IPS throughput (enterprise traffic mix): 1.4 Gbps
  • NGFW throughput (enterprise traffic mix): 1 Gbps
  • Threat protection throughput (enterprise traffic mix): 900 Mbps
  • Firewall throughput (1518-byte UDP): 10 Gbps
  • Firewall throughput (512-byte UDP): 10 Gbps
  • Firewall throughput (64-byte UDP): 7 Gbps
  • Firewall latency (64-byte UDP): 3.23 µs
  • Firewall throughput: 10.5 Mpps
  • VPN throughput (512-bit IPSec): 6.5 Gbps
  • VPN throughput (SSL): 950 Mbps
  • SSL inspection throughput: 715 Mbps
  • Application control throughput: 1.8 Gbps
  • CAPWAP throughput: 9 Gbps
Remote Management ProtocolHTTP, HTTPS
Status IndicatorsPower, status, PoE, HA, bypass
Power
Installed Qty1
Max Supported Qty2
Power Consumption Operational96 Watt
Power DeviceExternal power adapter
Power Over Ethernet (PoE) SupportedPoE+
Power RedundancyOptional
Voltage RequiredAC 100-240 V (50/60 Hz)
Processor / Memory / Storage
Processors Installed1 x Fortinet FortiASIC SOC4
Software / System Requirements
OS ProvidedFortiOS
