Hardware

Tripp Lite 8-Port DVI/USB KVM Switch with Audio and USB 2.0 Peripheral Sharing, 1U Rack-Mount, Single-Link, 1920 x 1200 (1080p)

$1,106.00

Mfr Part #:

Copied To Clipboard

Click To Copy

SHI Part #:

Copied To Clipboard

Click To Copy

Quick Details
KVM / audio / USB switch 8 x KVM / audio / USB 1 local user rack-mountable AC 100

Tripp Lite 8-Port DVI/USB KVM Switch with Audio and USB 2.0 Peripheral Sharing, 1U Rack-Mount, Single-Link, 1920 x 1200 (1080p)

KVM / audio / USB switch
8 x KVM / audio / USB
1 local user
rack-mountable
AC 100
240 V
TAA Compliant

Additional Details
Price:	$1,106.00
Mfr Part #:	B024-DUA8-SL
SHI Part #:	34450076
Category:	Peripheral switch boxes
UNSPSC:	43211604
Manufacturer:	Eaton
Product Type:	Hardware

Control 8 Computers + Audio from a Single DVI Monitor, Keyboard and Mouse

? 8-port KVM switch recommended for IT managers needing centralized access to a variety of digital and analog servers

? Switch between connected computers via front-panel buttons, keyboard hotkeys or OSD

? Supports digital video resolutions up to 1920 x 1200 (1080p) and analog video resolutions up to 2048 x 1536

? Supports 2.1-channel surround sound with full bass response

? Also supports VGA display when connected to a DVI to VGA adapter

Connect Up to 512 Computers to One Original Console

? Expand the number of controlled computers by cascading up 3 levels of KVM switches

Multi-View Installation

? Allows stacking of up to 4 KVMs for connecting computers with up to 4 DVI outputs and displaying video on up to 4 console monitors

Independent USB 2.0 Peripheral Sharing

? 2-port front-panel USB 2.0 hub allows sharing of devices (printers, hard drives, scanners, webcams) between connected computers

Multilingual On-Screen Display

? OSD supports English, German, Japanese, Traditional Chinese, Simplified Chinese, Spanish, Russian and French

? Text-based interface offers direct access to every connected computer

? Backs up and restores KVM configuration and user profile info

Dual-Tier Password Protection

? Enhances security for administrator and up to 4 users

Hot-Plugging and Auto Scan

? Computers and devices can be disconnected and reconnected without KVM switch shutdown

? Automatically switches between ports every 5 seconds for convenient monitoring

Flexible Keyboard/Mouse Applications

? Console mouse port emulation/bypass supports most mouse drivers and multifunction mice

? Complete keyboard emulation for error-free booting

Easy Setup and Use

? Plug-and-play operation with no software or drivers to install

? Durable metal housing mounts in 1U of space in EIA-standard 19 in. rack

? Upgradable firmware to ensure up-to-date operation

? Compatible with Windows, Mac, Sun and Linux

TAA-Compliant

? Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.

Audio/Video Cables

Tripp Lite 10ft USB 2.0 Hi-Speed A/B Device Cable Shielded M/M 10'

USB cable
USB (M) to USB Type B (M)
USB 2.0
3 m
molded
black

$6.00

Tripp Lite 6ft USB Cable Hi-Speed Gold Shielded USB 2.0 A/B Male / Male 6'

USB cable
USB (M) to USB Type B (M)
USB 2.0
1.8 m
black

$6.00

Tripp Lite 6ft DVI Dual Link Digital TMDS Monitor Cable Shielded DVI-D M/M 6'

DVI cable
DVI-D (M) to DVI-D (M)
1.8 m
molded

$14.00

General Information
Category	Peripheral switch boxes
Description	Tripp Lite 8-Port DVI/USB KVM Switch with Audio and USB 2.0 Peripheral Sharing, 1U Rack-Mount, Single-Link, 1920 x 1200 (1080p) - KVM / audio / USB switch - 8 x KVM / audio / USB - 1 local user - rack-mountable - AC 100 - 240 V - TAA Compliant
Manufacturer	Eaton
MSRP	$1,687.05
UNSPSC	43211604
Main Specifications
Dimensions & Weight / Depth	16 cm
Dimensions & Weight / Height	4.39 cm
Dimensions & Weight / Weight	2.81 kg
Dimensions & Weight / Width	43.69 cm
Header / Brand	Tripp Lite
Miscellaneous / Product Color	Black
Networking / Form Factor	Rack-mountable
Networking / Ports Qty	8
Networking / Type	KVM / audio / USB switch
Packaged Quantity	1
Service & Support / Type	3-year warranty
Dimensions & Weight
Depth	16 cm
Height	4.39 cm
Weight	2.81 kg
Width	43.69 cm
Environmental Parameters
Humidity Range Operating	0 - 80% (non-condensing)
Max Operating Temperature	50 °C
Max Storage Temperature	60 °C
Min Operating Temperature	0 °C
Min Storage Temperature	-20 °C
Expansion / Connectivity
Interfaces	8 x DVI-I input 8 x USB 2.0 Type B 8 x audio / headphones mini-jack 8 x audio / microphone mini-jack 1 x DVI-I output 1 x VGA output HD-15 2 x audio output mini-jack 2 x audio input mini-jack 2 x keyboard (USB) / mouse (USB) Type A 2 x USB 2.0 Type A 1 x management RJ-11
General
Built-in Devices	USB 2.0 hub
Device Type	KVM / audio / USB switch - 8 ports - cascadable
Enclosure Type	Rack-mountable 1U
Features	On-Screen Display, firmware upgradable, Auto Scan Mode, Pushbutton/Hotkey switching, administrator's password
Keyboard / Mouse Interface	USB
KVM Local Users Qty	1 local user
Max Resolution	2048 x 1536
Ports	8 x KVM / audio / USB
Status Indicators	KVM, port status, power, scan, USB
Subtype	DVI / audio
Manufacturer Warranty
Service & Support	Limited warranty - 3 years
Miscellaneous
Cables Included	1 x serial cable - 1.8 m 2 x DVI / USB cable - 1.8 m
Color	Black
Compliant Standards	FCC, UL, cUL, PSE Mark, BSMI, RoHS, Plug and Play
Included Accessories	Rubber feet, grounding kit
Rack Mounting Kit	Included
TAA Compliant	Yes
Power
Power Consumption Operational	6.36 Watt
Power Device	External power adapter
Voltage Required	AC 100 - 240 V (50/60 Hz)
